(Passivated Emitter and Rear Cell), which exploit light reflection and improve conversion effciency thanks to a dielectric layer on the rear side.
| Specifications |
TBS 110WS |
TBS 170WS |
TBS 185WS |
| Rated power (Pmax): | 110 W | 170 W | 185 W |
| Rated voltage Pmax (Vmp): | 18.6 V | 22.55 V | 20.9 V |
| Rated current Pmax (Imp): | 5.92 A | 7.54 A | 8.85 A |
| Open circuit voltage (Voc): | 22.01 V | 26.65 V | 24.7 V |
| Closed circuit current (Isc): | 6.27 A | 8.05 A | 9.38 A |
| Module efficiency ( m): | 20.54 % | 20.62 % | 20.68 % |
| Working temperature: | -40°C ~ + 80°C | -40°C ~ + 80°C | -40°C ~ + 80°C |
| Cable (length/cross-section): | 900 mm/2.5 mm2 | 900 mm/2.5 mm2 | 900 mm/2.5 mm2 |
| Module size (LxWxH) (without feet): | 1160x450x30 mm | 1230x670x30 mm | 1230x705x30 mm |
| Weight (without feet): | 5.7 kg | 9.0 kg | 10.0 kg |
